Remanufactured Turbo / Turbocharger 806497 783248 - Peugeot 3008 308 407 508 5008 Citroen C4 C5 2.0 HDi | 136-200HP
Remanufactured turbocharger covering Garrett 806497 and 783248 turbo families, fitted to selected Peugeot, Citroen and DS 2.0 HDi / BlueHDi diesel applications. Suitable for models including Peugeot 3008, 308, 407, 5008, 508, RCZ, Citroen C4, C4 Picasso, C5 and DS4. Covers 136HP, 150HP, 163HP and selected 200HP / 100-147kW 1997cc engines, depending on model and engine code.
OEM-spec remanufactured turbocharger covering part numbers 806497-5002S, 806497-5001S, 806497-5003S, 783248-5005S, 783248-5004S and 783248-5003S. OE references include 9688361580 and 9677062780. Commonly searched as Peugeot 508 2.0 HDi turbo, Peugeot 3008 2.0 HDi turbocharger, Citroen C5 2.0 HDi turbo and 806497 turbo replacement.
Please check your part number before ordering. Call 07440 707 255 or 01323 301 999 for help.
Images are for illustration purposes only.
Remanufactured Turbo / Turbocharger 806497 783248 - Peugeot 3008 308 407 508 5008 Citroen C4 C5 2.0 HDi | 136-200HP
Supplied with gaskets included, without the original manufacturer’s box
Used across many PSA 2.0 HDi diesel applications, this reman turbo is suitable for selected Peugeot 3008, 308, 407, 5008, 508, RCZ, Citroen C4, C4 Picasso, C5 and DS4 models. It covers compatible 2.0 HDi and BlueHDi engines where the original turbo matches the listed Garrett or OE part numbers.
The main turbo references covered include 806497-5002S, 806497-5001S, 806497-5003S, 783248-5005S, 783248-5004S and 783248-5003S. OE references include 9688361580 and 9677062780. These units are commonly used on 2.0 HDi engines producing 136HP, 150HP and 163HP, with some listed applications including 200HP Hybrid4 variants.
This remanufactured Peugeot / Citroen 2.0 HDi turbocharger is built to OEM specification as a direct replacement unit for compatible DW10 diesel applications. It is designed to restore correct boost pressure, drivability and engine performance when fitted to the correct vehicle. For fitting, diagnostics, exchange supply and related workshop support, see our turbocharger services.
Product Highlights
- Remanufactured OEM-spec turbocharger
- Covers Garrett turbo families: 806497 and 783248
- Supplied with gaskets included
- Main part numbers include: 806497-5002S, 806497-5001S, 806497-5003S, 783248-5005S, 783248-5004S and 783248-5003S
- Fits selected Peugeot, Citroen and DS 2.0 HDi / BlueHDi models
- Suitable for 136-200HP 2.0 diesel applications
- Engine codes include: AHS, AHV, AHX, RHC, RHD, RHE, RHH and RHR
- Engine family includes: DW10FD, DW10CTED4, DW10CB and DW10BTED4
- OE references include: 9688361580 and 9677062780
- Direct replacement - no modification required
- Sold on an exchange basis
- Fitting instructions
Exchange Basis - How It Works
This turbocharger is supplied on an exchange basis, which means we require your old unit to be returned. You can arrange this in whichever way is most convenient:
- Pay the surcharge - your replacement turbo is dispatched immediately. The surcharge is refunded in full once we receive your old unit. Please return your old turbocharger within 21 days.
- Send your old turbo first - once received, we will dispatch your replacement the same day with no surcharge required.
- Visit our workshop - bring your old unit to our Eastbourne workshop and we will exchange it on-site.
Vehicle Compatibility
This turbocharger fits the following makes, models, and engine specifications:
Note: PSA 2.0 HDi applications can vary by model year, emissions standard and engine code. Please match by turbo part number or OE reference before ordering.
| Make | Model | HP | kW | Engine | Engine Code | Year |
|---|---|---|---|---|---|---|
| Peugeot | 3008 I MPV 2.0 HDi / BlueHDi | 150 / 163 | 110 / 120 | 2.0 HDi / 1997cc | RHE / RHH / DW10 variants | 06/2009-08/2016 |
| Peugeot | 308 I / 308 SW I / 308 CC 2.0 HDi | 163 | 120 | 2.0 HDi / 1997cc | RHH / DW10CTED4 | 06/2009-12/2014 |
| Peugeot | 407 / 407 SW 2.0 HDi | 163 | 120 | 2.0 HDi / 1997cc | RHH / DW10CTED4 | 06/2009-12/2010 |
| Peugeot | 5008 2.0 HDi / BlueHDi | 136 / 150 / 163 | 100 / 110 / 120 | 2.0 HDi / 1997cc | RHD / RHE / RHH / DW10 variants | 06/2009-03/2017 |
| Peugeot | 508 I / 508 SW I 2.0 HDi | 136 / 163 / 200 | 100 / 120 / 147 | 2.0 HDi / 1997cc | RHD / RHH / DW10 variants | 11/2010-12/2018 |
| Peugeot | RCZ 2.0 HDi | 163 | 120 | 2.0 HDi / 1997cc | RHH / DW10CTED4 | 03/2010-12/2015 |
| Citroen | C4 II 2.0 HDi / BlueHDi 150 | 150 | 110 | 2.0 HDi / 1997cc | AHS / AHV / AHX / RHE / DW10 variants | 11/2009- |
| Citroen | C4 Picasso I / C4 Grand Picasso I 2.0 HDi | 150 / 163 | 110 / 120 | 2.0 HDi / 1997cc | RHE / RHH / DW10CTED4 | 07/2009-08/2013 |
| Citroen | C5 III / C5 III Break 2.0 HDi / BlueHDi | 150 / 163 | 110 / 120 | 2.0 HDi / 1997cc | RHE / RHH / DW10CTED4 | 04/2009-05/2017 |
| DS | DS4 2.0 HDi 165 | 163 | 120 | 2.0 HDi / 1997cc | RHH / DW10CTED4 | 04/2011-07/2015 |
Associated part numbers: 806497-5002S, 806497-0002, 806497-2, 806497-5001S, 806497-0001, 806497-1, 806497-5003S, 806497-0003, 806497-3, 783248-5005S, 783248-0005, 783248-5, 783248-5004S, 783248-0004, 783248-4, 783248-5003S, 783248-0003, 783248-3, 9688361580, 9677062780
Fitting Advice
We always recommend having your replacement turbocharger fitted by a qualified mechanic. Correct installation is essential to ensure proper fitment, reliable operation, and long service life from day one.
You can read our full fitting instructions here.
It is also essential that the root cause of the original turbocharger failure is identified before fitting the replacement. In many cases there is an underlying issue that also needs attention, such as a blocked DPF. This is one of the most common contributing factors, and fitting a new turbo without resolving it can place the replacement under unnecessary strain.
We also offer a professional DPF cleaning service if required.
Fitting Service at Turboworks
If you would like us to carry out the installation, our Eastbourne workshop is staffed by experienced mechanics whose day-to-day work includes turbocharger replacement, diagnostics, and related repairs.
If you are looking for a turbo specialist, click here to request a fitting quote, or call us directly on 07440 707 255 or 01323 301 999.
Please note that we do not offer a while-you-wait service. We will arrange a booking time that works for you.
Warranty Information
Unless otherwise stated, warranty is provided to the original purchaser for repair or replacement of the turbocharger for up to 2 years from date of purchase or 12,000 miles (whichever occurs first). Warranty covers the turbocharger for faulty workmanship or components and does not extend to damage caused by misuse in fitting or operation.
The reason for failure of the previous turbocharger must be rectified prior to fitting a replacement. Air and oil filters, engine oil, gaskets and the oil feed pipe need to be changed or replaced. Proof of purchase of components may be required to support any claims.
Proof and date of the original purchase will be required before considering any warranty claim, and the unit must be returned complete. Any attempt to dismantle or repair the unit will invalidate the conditions of warranty. Warranty does not cover any cost of labour or materials required to remove or reinstall the turbocharger.
Delivery & Dispatch
Delivery is available within the United Kingdom and internationally, subject to availability. Free delivery applies to turbochargers supplied to UK mainland addresses unless otherwise stated. Delivery timeframes provided are estimates only.
Stock items are typically dispatched the same day when orders are placed before 3 pm. Orders placed after 3 pm, over a weekend, or on a bank holiday will normally be dispatched on the next working day.
Non-stock or special-order items are subject to lead times, which will be confirmed separately. Certain geographical locations may require extended delivery periods.
Please inspect goods immediately upon delivery. Where packaging is visibly damaged, delivery should be refused and reported without delay.
Returns
If you need to return a turbocharger or send a unit back to us, please contact us first so we can advise on the correct process.
Where a unit is being returned or collected, it must be securely packaged in a suitable, rigid cardboard box and adequately protected using appropriate packaging materials. Non-essential components, including oil feed pipes, oil return pipes, sensors, wiring, brackets, and ancillary fittings, should be removed before sending.
Where return shipment is arranged by the customer, please retain proof of shipment and tracking details.
Turbocharger Guides & Advice
Please check your turbocharger part number before ordering. Many vehicles use more than one turbocharger version depending on model year, engine code, power output, emissions setup and actuator type.
If you are unsure whether your turbocharger has failed, or you want to understand common causes of turbo problems before ordering, visit our technical information hub.
For Turboworks updates, buying guidance and practical articles about replacement turbochargers, visit our blog.
Need help confirming compatibility?
Contact Turboworks on 07440 707 255 or 01323 301 999.
Based in Eastbourne - specialists in turbocharger replacement, supply, and diagnostics.
- Condition:
- Remanufactured
- Fits to:
- Citroen C4, C5, DS4
Peugeot 3008, 308, 407, 5008, 508, RCZ - Engine Code:
- AHS, AHV, AHX, RHC, RHD, RHE, RHH, RHR
- Power (BHP):
- 136 / 150 / 163 / 200 HP
- Capacity (cm3):
- 2.0 HDi / 1997cc
- Years:
- Citroen C4 II 2.0 HDi / BlueHDi 150 2009-
Citroen C4 Picasso I / C4 Grand Picasso I 2.0 HDi 2009-2013
Citroen C5 III / C5 III Break 2.0 HDi / BlueHDi 2009-2017
Citroen DS4 2.0 HDi 165 2011-2015
Peugeot 308 I / 308 SW I / 308 CC 2.0 HDi 2009-2014
Peugeot 407 / 407 SW 2.0 HDi 2009-2010
Peugeot 508 I / 508 SW I 2.0 HDi 2010-2018
Peugeot 3008 I MPV 2.0 HDi / BlueHDi 2009-2016
Peugeot 5008 2.0 HDi / BlueHDi 2009-2017
Peugeot RCZ 2.0 HDi 2010-2015 - Part numbers:
- 806497-5002S, 806497-0002, 806497-2, 806497-5001S, 806497-0001, 806497-1, 806497-5003S, 806497-0003, 806497-3, 783248-5005S, 783248-0005, 783248-5, 783248-5004S, 783248-0004, 783248-4, 783248-5003S, 783248-0003, 783248-3,
- OE numbers:
- 9688361580, 9677062780
